- Coil Spring Specs
- C59-342 Stock Height, Stock Load
- C59-344 (45mm - 1.75") Stock Load
- C59-300 (50mm - 2") Stock Load (SC59-001-ISO REQUIRED)
- C59-302 (60mm - 2.5") Stock Load / (50mm-2") 110-175lb Load (SC59-001-ISO REQUIRED)
- 3-way Adjustable shocks provide maximum adjustability to provide the perfect ride quality for you.
- 10 Stage High Speed Compression - For aggressive, high speed off roading through ruts and holes.
- 20 Stage Low Speed Compression - For creepy crawling and cornering
- 15 Stage Rebound - Control your coils, prevent bucking
- 50mm/60mm CNC Machined High Flow Billet Aluminium Race Piston
- 2.2"/2.6" Diameter precision honed shock bodies with HD 3mm thick walls
- Upgraded 3 Stage FKM/HNBR Sealing System
- TSUGAMITM CNC machined components for precise tolerances
- ParkerTM Braided High Pressure Hoses
- 5140 HV900 Hard Chrome Plated, Heat treated 18mm Micro-Polished high strength Shock Shaft with a minimum tensile strength exceeding 700MPA
- T6 6061 Height Adjustable Spring Seat
- Carbon-Fibre/PTFE/Disulphide composite wear band for the ultimate in low-friction, low€�wear performance
- 60mm Full 6063 aluminum remote reservoir
- Lightweight CNC Machined Low Friction floating piston
- High Quality O.E.M. Grade Natural Rubber Bushings
- Single Piece Lower Leg
- EDP Surface Protection
- Direct Bolt-On Design
- CNC TIG Precision Welded Body End Mounts
- Fully Rebuildable Design
***Coil seat should be set at 164mm (6.45") from the strut bushing eye.***
