Portable Power Station Specification
View ElecHive 2500 User Manual
|
Battery |
|
|
Capacity |
2500Wh |
|
Cell Chemistry |
NMC(Lithium-Nickel-Manganese Cobalt-Oxide) |
|
Recharging Temperature |
32-104°F/ 0-40°C |
|
Operating Temperature |
-4-104°F/ -20-40°C |
|
Shelf Life |
More than 2 Years (After fully charged) |
|
Life Span |
2300 Cycles (80%) |
|
Weight |
40lbs/18.3kg |
|
Size |
12.9*9.6*11.3 inch/ 32.8*24.4 *28.7cm |
|
Storage Temperature & Humidity |
-40~140°F/-40 ~60°C, <95%RH |
|
DC Output |
|
|
12V Anderson Port |
10.5~13.4V, 300W/25A Max |
|
24V Anderson Port |
19.5~25.2V, 500W/25A Max |
|
12V DC5521 Port |
10.5~13.4V, 120W/10A Max |
|
2 x USB-A |
5/9/12V, 18W QC3.0 |
|
1 x USB-C Bi-direction full PD |
5/9/12/15/20V, 100W/5A Max |
|
1 x USB-C |
5/9/12V, 18W Max |
|
AC Output |
|
|
4 x US wall outlet or 3 x Universal wall outlet |
110V, 60Hz, 2200W/20A max Continuous, or 230V, 50Hz, 2200W/10A max continuous 4400W Surge Peak |
|
Input / Charge |
|
|
Normal Charging (Anderson Port) |
Solar (Open Circuit Voltage) 240W/10A Max(~11hours to full) |
|
DC Charger 12~30V 240W/10A Max(~11hours to full) AC Charger 100~240V, 50/60Hz 3.5A(~11hours to full) |
|
|
Fast Charging (Anderson Port) |
Solar (Open Circuit Voltage) 30~75V 1250W/26A Max (~3hours to full) |
|
DC Charger 30~38V 600W/16.7A Max(~5hours to full) AC Charger 100~130V, 60Hz 6A (US V.)/ 200~240V 50Hz 3.2A(Others V.)(~5hours to full) |
|
|
DC Charger 42~60V 1250W/26A Max(~2.5hours to full) AC Charger 100~130V, 60Hz 12A (US V.)/ 200~240V 50Hz 6.5A(Others V.)(~2.5hours to full) |
|
|
Mode |
|
|
Auto-sleep switch AC frequency(JP) |
ON/OFF (US) 60Hz/50Hz (JP) |
|
Charge/Discharge Percentage |
90%/100% |
